Plywood
Veneers from high quality logs are mechanically dried and they undergo stress relieving process, which are assembled insuch a way to from a balanced construction . High quality fortified synthetic resins are used for gluing the veneers. Glue line is poisoned by special formulations of chemicals to make Caliber Plywood safe against borers. It is hot pressed under proper temperature and more than 16 Kg/cm specific pressure. Conditioning is done after pressing, followed by preservative treatment.
Applications:
Partition and paneling, ceilings in public rooms and corridors, floor underlayment, computer rooms furniture, bus bodies, railway coaches, milk booths, sign boards, insert in panel doors, storage racks.
Technical Specification | ||
Test | Required Value | Observed |
Value | ||
Moisture Contents | 5% - 15% | As per ISI Req. |
Dimension | Length+5mm, Width+2mm Thickness 2-8mm+5%, < 6mm+10% | With limit |
Sp. Gravity | As per ISI Req. | |
Resistance to water (3 cycles of 8hr boiling & 16 HR. Drying at 76 C) | ||
- Adhesion to plies | Min. Pass Standard | Excellent |
Resistance to Micro-Organism | ||
- Adhesion to plies Static Bending Test a) Modulus of Elasticity |
Min. Pass Standard | Excellent |
- along the grain Avg. | Min. 5000 N/sq.mm | As per ISI Req. |
- along the grain Avg. b) Modulus of Rupture |
Min. 2500 N/sq.mm | As per ISI Req. |
- along the grain Avg. | Min. 40 N/sq.mm | As per ISI Req. |
- along the grain Avg. | Min. 20 N/sq.mm | As per ISI Req. |
Flush Doors
These are made from high Density Farm Timbers, which are chemically treated and well sesasoned. Battens are edge glued to make these doors durable and dimensionally treated and well seasoned. Battens are edge gludeto make these doors durable and dimensionally stable. Special formulations of chemicals are used to poison the glue line against borers and fungus. External preservative treatment is given to make these doors perfectly resistant to all the Micro Organisms.Caliber Flush doors are available in all sizes and thickness. Flush doors are laminated with decorative veneers are per customers' requirements.
Applications:
Door in homes and offices.
Technical Specification | ||
Test | Requirment of IS 2202 | Test Result |
Dimensions & Squareness | Length + 0/mm | +3mm |
Width +0/mm | +2mm | |
Thickness +/-1mm | +.6mm | |
Squareness: not more than | .5mm | |
1mm per 500mm length | ||
General Flatness | 6mm | 2.0mm |
Local Planeness | 0.5mm | 0.2mm |
Impact Indentation | 0.2mm | 0.10mm |
Flexture Test | Max. Deflection 5mm | Max. Deflection 3mm |
Edge Loading Tests | Residual deflection 0.5mm | Residual deflection .25mm |
Lateral buckling 2mm | 1mm | |
Sock Resistant Tests | Should withstand 5 impacts | Can withstand 10 impacts |
Misuse Tests | No Permanent Deformation of the Fixing |
No Permanent Deformation |
End Immersion Tests | No Delamination | No Delamination |
Knife/Glue Adhesion Test | Pass Standard | Excellent |
Screw Withdrawl | 1000N | 1800N |
Slamming Tests | No Visible Damage After 50 Drops | No Damage |
Buckling Test | Pass Standard | Excellent |
Block Board
These are made out of excellent quality of Plantation Timbers. logs are quarter sawn into Planks using SDR method, which are chemically treated and well seasoned before converting into battens in a multiple ripsaw. Battens are sandwiched between two glued mechanically dried veneers and are pressed in hot press under accurate temperature and pressure. Quarter sawing of logs and proper seasoning of planks make it dimensionally stable and treatment of planks,poisoning of glue line and preservative treatment of finished block board make Caliber plywood durable and safe against borers.
Applications:
Cabinets,Almirahs and othe furniture,Door Partitions,Shelves and other interior applications;Roofing, Fencing,and other external applications.
Technical Specification | ||
Test | Required Value | Observed Value |
Dimensional Changes caused by Humidity a) Changes, mm |
||
from 65% RH to 90% RH | + 1mm Max. | As per ISI |
from 65% RH to 40% RH | - 1mm Max. | Requirement |
b) Local Planeness | <1/150 | As per ISI Req. |
c) At the extreme range of humidity |
No del-lamination at the extreme range of humidity |
No de-limination observed |
Adhesion of the plies | Minimum pass standard | Excellent |
Resistance to water | No de-lamination after 72 hours boiling |
No de-lamination |
Resistance to Micro organisms | No appreciable sign of separation at edges. |
o separation at edges |
Modulus of Elasticity | Min. 5000 N/sq.mm | As per ISI Req. |
Modulus of Repture | Min. 50 N/sq.mm | As per ISI Req. |
